Redbox: the Radio Shack Dialer Modification
So you've heard about the redbox and you'd like to know more about how they are built.
Here's how:
Go out and buy a Radio Shack memory dialer - Part #43-146.
The device looks like this:
Click here for a more detailed shot. A crystal around 6.5 MHz is required. A 6.5536 MHz is more widely used and can be used as a replacement. To modify the device, cut or desolder the existing crystal (it is shown as the small cylindrical object at the bottom of the picture) and resolder the new crystal in its place. The new crystal is the ovular object to the right of the black blob. The crystals come in many different shapes and sizes. The tricky part is placing the crystal in a location that will permit the case to close properly.
The * button will now produce a sound similar to the coin tone. For added convenience, program the three
programmable buttons with a single tone (nickel), two *'s (dime), and 5 *'s (quarter).
For more information on the RedBox, check out the
HACK-FAQ!
